Poller Configuration

Poller is a service which is responsible for querying SNMP devices using the SNMP GET and WALK functionalities. Poller executes two main types of tasks:

  • The Walk task executes SNMP walk. SNMP walk is an SNMP application that uses SNMP GETNEXT requests to collect SNMP data from the network and infrastructure of SNMP-enabled devices, such as switches and routers. It is a time-consuming task, which may overload the SNMP device when executed too often. It is used by the SC4SNMP to collect and push all OID values, which the provided ACL has access to.

  • The Get task is a lightweight task that queries a subset of OIDs defined by the customer. This task monitors OIDs, such as memory or CPU utilization.

Poller has an inventory, which defines what and how often SC4SNMP has to poll.

Poller configuration file

The poller configuration is kept in a values.yaml file in the poller section. values.yaml is used during the installation process for configuring Kubernetes values.

See the following poller example configuration:

poller:
  usernameSecrets:
   - sc4snmp-hlab-sha-aes
   - sc4snmp-hlab-sha-des
  logLevel: "WARN"
  inventory: |
    address,port,version,community,secret,security_engine,walk_interval,profiles,smart_profiles,delete
    10.202.4.202,,2c,public,,,2000,,,

Info

The header’s line (address,port,version,community,secret,security_engine,walk_interval,profiles,smart_profiles,delete) is necessary for the correct execution of SC4SNMP. Do not remove it.

IPv6 hostname resolution

When IPv6 is enabled and device is dual stack, the hostname resolution will try to resolve the name to the IPv6 address first, then to the IPv4 address.

Define log level

The log level for poller can be set by changing the value for the key logLevel. The allowed values are: DEBUG, INFO, WARNING, ERROR, CRITICAL or FATAL. The default value is INFO.

Define usernameSecrets

Secrets are required to run SNMPv3 polling. To add v3 authentication details, create the k8s Secret object: SNMPv3 Configuration, and put its name in poller.usernameSecrets.

Append OID index part to the metrics

Not every SNMP metric object is structured with its index as a one of the field values. We can append the index part of OID with:

poller:
  metricsIndexingEnabled: true

So the following change will make this metric object (derived from the OID 1.3.6.1.2.1.6.20.1.4.0.0.443)

{
   frequency: 5
   metric_name:sc4snmp.TCP-MIB.tcpListenerProcess: 309
   mibIndex: 0.0.443
   profiles: generic_switch
}

out of this object:

{
   frequency: 5
   metric_name:sc4snmp.TCP-MIB.tcpListenerProcess: 309
   profiles: generic_switch
}

Disable automatic polling of base profiles

There are two profiles that are being polled by default, so that even without any configuration set up, you can see the data in Splunk. You can disable it with the following pollBaseProfiles parameter:

poller:
  pollBaseProfiles: false

Configure inventory

To update inventory, see Update Inventory and Profile.

The inventory section in poller has the following fields to configure:

Field Description Default Required
address The IP address which SC4SNMP should collect data from, or name of the group of hosts. General information about groups can be found on the Configuring Groups page. YES
port SNMP listening port. 161 NO
version SNMP version, the allowed values are 1, 2c, or 3. YES
community SNMP community string, this field is required when the version is 1 or 2c. NO
secret The reference to the secret from poller.usernameSecrets that should be used to poll from the device. NO
security_engine The security engine ID required by SNMPv3. If it is not provided for version 3, it will be autogenerated. NO
walk_interval The interval in seconds for SNMP walk. This value needs to be between 1800 and 604800. 42000 NO
profiles A list of SNMP profiles used for the device. More than one profile can be added by a semicolon separation, for example, profile1;profile2. For more information about profiles, see Profile Configuration. NO
smart_profiles Enables smart profiles. Its allowed values are true or false. true NO
delete A flag that defines if the inventory should be deleted from the scheduled tasks for WALKs and GETs. Its allowed value are trueor false. The default value is false. false NO

See the following example:

poller:
    inventory: |
      address,port,version,community,secret,security_engine,walk_interval,profiles,smart_profiles,delete
      10.202.4.202,,2c,public,,,2000,my_profile1,,
      example_group_1,,2c,public,,,2000,my_profile2;my_profile3,,

Update Inventory

Adding new devices for values.yaml is resource expensive, and can impact performance. As it interacts with hardware networking devices, the updating process requires several checks before applying changes. SC4SNMP was designed to prevent changes in inventory tasks more often than every 5 minutes.

To apply inventory changes in values.yaml, the following steps need to be executed:

  1. Edit values.yaml
  2. Check if the inventory pod is still running using the following execute command:
microk8s kubectl -n sc4snmp get pods | grep inventory

If the command return pods, wait and continue to execute the command again, until the inventory job finishes.

If you really need to apply changes immediately, you can get around the limitation by deleting the inventory job using the following command:

microk8s kubectl delete job/snmp-splunk-connect-for-snmp-inventory -n sc4snmp

After running this command, you can proceed with upgrading without a need to wait.

  1. Run upgrade command :
microk8s helm3 upgrade --install snmp -f values.yaml splunk-connect-for-snmp/splunk-connect-for-snmp --namespace=sc4snmp --create-namespace

Info

If you decide to change the frequency of the profile without changing the inventory data, the change will be reflected after the next walk process for the host. The walk happens every walk_interval, or during any change in inventory.

Upgrade with the csv file

You can update inventory by making changes outside of the values.yaml. It can be put into a separate csv file and upgraded using --set-file poller.inventory=<path_to_file>.

See the following example of an CSV file configuration:

address,port,version,community,secret,security_engine,walk_interval,profiles,smart_profiles,delete
10.202.4.202,,2c,public,,,3000,my_profile,,

See the following example of an upgrade command with a CSV file:

microk8s helm3 upgrade --install snmp -f values.yaml --set-file poller.inventory=inventory.csv splunk-connect-for-snmp/splunk-connect-for-snmp --namespace=sc4snmp --create-namespace
